Get to know Surface Pro 4
Not sure where to plug something in or how to turn up the volume? We’ve got you covered. Here are a couple of diagrams to help you.
- Touchscreen
- Speaker
- Power button
- Infrared camera
- Front camera
- Front privacy light
- Front microphone
- Mini DisplayPort
- USB 3.0
- Charging port
- MicroSDXC card slot
- Pen
- Back camera
- Back privacy light
- Back microphone
- Volume button
- Headphone jack
- Magnetic storage for pen
- Kickstand
Surface Pro 4 features
Express yourself
Enjoy a natural writing experience with a pen that feels like an actual pen. Use Surface Pen to launch Cortana (not available in all languages and countries/regions) or open OneNote and quickly jot down notes or take screenshots. Keep your pen handy with the convenient magnetic pen storage on the side of Surface Pro 4.
Surface Pro 4 features two cameras for taking photos and recording video: an 8-megapixel rear-facing camera with autofocus and a 5-megapixel, high-resolution, front-facing camera. Both cameras record video in 1080p, with a 16:9 aspect ratio. Privacy lights are located on the right side of both cameras.
Surface Pro 4 also features an infrared (IR) face-detection camera so you can sign in to Windows without typing a password.
Work, play, watch, listen
Flip out the 150-degree-angle kickstand and work or play comfortably at your desk, on the couch, or while giving a hands-free presentation.
Stay connected
Surface Pro 4 has the ports you expect in a full-feature laptop.
- Full-size USB 3.0 portConnect a USB accessory like a mouse, printer, Ethernet adapter, USB drive, or smartphone.
- Surface Connect for chargingWhen your battery is low, attach the included power supply to the Surface Connect charging port.
- MicroSD card slotUse the microSD card slot and a microSD card (sold separately) for file transfer and extra storage.
- Mini DisplayPort version 1.2Share what’s on your Surface screen by connecting it to an HDTV, monitor, or projector. (Video adapters are sold separately.)
- 3.5 mm headset jackPlug in your favorite headset for a little more privacy when listening to music or conference calls.over connectorsClick in the thin, light, Type Cover for Surface Pro 4 (sold separately) so you’ll always have a keyboard when you’re on the go.
Hardware specifications
| Dimensions | 11.50” x 7.93” x 0.33” (292.10mm x 201.42mm x 8.45mm) |
| Display | Screen: 12.3” PixelSense™ DisplayResolution: 2736 x 1824 (267 PPI)Aspect Ratio: 3:2Touch: 10 point multi-touch |
| Memory | 8GB, or 16GB RAM |
| Processor | 6th Generation Intel® Core™ m3, i5, or i7 |
| Security | TPM chip for enterprise security Enterprise-grade protection with Windows Hello(1) face sign-in |
| Software | Windows 10 Pro Office 30-day trial |
| Sensors | Ambient light sensor Accelerometer Gyroscope |
| What’s in the box | Surface Pro 4Surface Pen* Power SupplyQuick Start GuideSafety and warranty documents |
| Weight | I5: 1.73lbs (786g)I7: 1.73lbs (786g) |
| Storage(2) | Solid state drive (SSD) options: , 256GB, 512GB, or 1TB |
| Battery life | Up to 9 hours of video playback(3) |
| Graphics | I5: Intel® HD graphics 520I7: Intel® Iris™ graphics |
| Ports | full-size USB 3.0 microSD™ card reader (UHS-I)Surface Connect™Headset jackMini DisplayPort Cover port |
| Cameras, video, and audio | Windows Hello face sign-in camera (front-facing)5.0MP front-facing camera with 1080p HD video8.0MP rear-facing autofocus camera with 1080p HD videoStereo microphonesStereo speakers with Dolby® Audio™ Premium |
| Wireless | 802.11ac Wi-Fi wireless networking IEEE 802.11a/b/g/n compatibleBluetooth Wireless 4.0 technology |
| Exterior | Casing: MagnesiumColor: SilverPhysical buttons: Volume, Power |
